STANDARD FEATURES
• Pull rating of 80 ft, P. Min, @ 100 lbs. tension on 56" reel diameter
• Tension rating of 80 ft. P. Min @ 400 lbs. tension on 56 to 25" reel diameter
• Frame welded from tubular steel 2-1/2 x 2-1/4 x 1/4, wall with bolt down angles on 4 corners
• Reel shaft hollow tubing 2-5/8 OD x 5/16 wall
• Steel roller chain drive
• Chain guard
• Disconnect at driving sprocket for freewheeling
• Brake disc on reel shaft
• Manual brake caliper
• Hydraulic Rewind consisting of a hydraulic motor mounted with capacity for 20,000 in/lbs. torque based a 2,000 PSI supply; has a "freewheel" disconnect feature. (Customer to supply quick disconnects.)
• Steel sandblasted, primed and painted with Dupont Imron polyurethane paint for maximum protection
